Description

Powers Power-Stud® Stainless Steel Wedge Anchor

Wedge Anchors 304 Stainless Steel:

• Diameter = Drill Size
• 1/4″ Diameter – 1-1/8″ Minimum Embedment
• 3/8″ Diameter – 1-5/8″ Minimum Embedment
• 1/2″ Diameter – 2-1/4″ Minimum Embedment
• 5/8″ Diameter – 2-3/4″ Minimum Embedment
• 3/4″ Diameter – 3-1/4″ Minimum Embedment

Box Quantities:

• 1/4″ Diameter x all lengths: 100
• 3/8″ Diameter x all lengths: 50
• 1/2″ Diameter x 2-3/4″, 3-3/4″, 4-1/2″, 5-1/2″ lengths : 50
• 1/2″ Diameter x 7″ length: 25
• 5/8″ Diameter x all lengths: 25
• 3/4″ Diameter x all lengths: 20

Features:

• Type 304 Stainless Steel
• Fully threaded, medium duty all-purpose anchor
• Anchors can be installed through the fixture for hole spotting not required
• Chamfered impact section prevents damage to threads
• Clip design prevents spinning during installation
• Nominal drill bit diameter same as anchor diameter
• Length ID stamped on each threaded anchor

Suitable Base Materials:

• Normal-weight Concrete
• Structural Lightweight Concrete
• Grouted Concrete Masonry (CMU)

Typical Applications:

• Lighting Standards and Base Plates
• Sills and Support Ledgers
• Retrofit Projects and Machinery Anchorage
• Food and Beverage Facilities
• Water Treatment Plants and Marine Applications
