Klein TI250 Rechargeable Thermal Imaging Camera

$428.55

Backorder

UOM: EA SKU: TI250 Categories: , , UPC: 092644692932

Description

Klein TI250 Rechargeable Thermal Imaging Camera

The Klein TI250 Rechargeable Thermal Imaging Camera includes:

  • Thermal imager
  • Micro-USB charging cable
  • Instructions
  • Carrying case

Features:

  • Catalog no. TI250
  • Thermal Imager with over 10,000 pixels to troubleshoot hot and cold spots
  • Adjustable emissivity from 0.01 to 1.00
  • Store and share images with optional microSD® Card (sold separately)
  • User selectable high and low temperature alarms:
        • From -4 to 752-Degree Fahrenheit (-20 to 400-Degree Celsius)
  • Select color palettes to best capture the event
  • Rechargeable lithium-ion battery

Specifications:

  • Type: Thermal Imager
  • Application: View Hot and Cold Spots For Instant Troubleshooting
  • Special Features:
        • High and Low Temperature Points
        • Crosshairs to Pinpoint Specific Temperatures
        • Options for Temperature Alarms
        • 3 Color Pallets
  • Display: 2.4” (6.1 cm) TFT LCD
  • Display Resolution: 320 x 240 Pixels
  • Sensor Type: VOx Microbolometer
  • Sensor Resolution: 10,800 Pixels
  • Thermal Sensitivity: <60 mK
  • Spectral Range: 8 to 14μm
  • Temperature Range: -4° to 752°F (-20° to 400°C)
  • Accuracy:
        • At More Than 212°F (100°C): +/- 2° or 2% (Whichever is Greater)
        • At Less Than 212°F (100°C): +/- 3° or 3% (Whichever is Greater)
  • Field of View: 50° +/- 3°
  • Laser Sighting: No
  • Emissivity: 0.01 to 1.00, Adjustable
  • Color Palettes: Ironbow, Rainbow, and Grayscale
  • Photo Capture: Yes
  • Maximum Frames per Second: <9 Hz
  • Memory: MicroSD® Card (not included)
  • Batteries: Lithium-Ion
  • Included: Rechargeable Thermal Imager, Micro-USB Charging Cable, Carrying Case, and Instructions
  • Overall Length: 3.1” (8.0 cm)
  • Overall Width: 1” (2.5 cm)
  • Overall Height: 3.1” (8.0 cm)
  • Material: ABS/PC, Electronic Components
  • Standards: CE and UKCA
  • Weight: 8.5 oz (241 g)
