Strongarm 033070 SACL300 30 Metric Ton Low Height Single Acting Cylinder

Description

Strongarm 033070 SACL300 30 Metric Ton Low Height Single Acting Cylinder

Strongarm 033070 SACL300 30 Metric Ton Low Height Single Acting Cylinder:

Features:

• Product no. 033063
• Model no. SACL100
• Designed for use in confined areas
• Complies with ASME B-30.1
• Made of durable high strength alloy steel
• Complete with mounting holes for fixture attachment
• Heavy duty plunger return springs
• Grooved plunger end with threaded hole allows mounting of tilt saddles
• Finished in baked enamel for superior corrosion resistance

Specifications:

• Capacity @ 700 Bar (10,000 PSI): 30 Ton
• Collapsed Height (A): 2.3″
• Duty Level: Super Heavy Duty
• Effective Area: 6.48 in²
• Extended Height (B): 2.8″
• Oil Capacity: 3,31 in³
• Outside Diameter (D): 4.61″ x 3.74″
• Piston Rod Diameter (F): 2.60″
• Rated Capacity: 30 T
• Spring Return: Yes
• Stroke Length: 0.51″
• Top Dimension (L): 1.89″
• Top Dimension (M): 1.77″
• Top Dimension (U): 2.05″
• Top Dimension (V): 0.39″
