Description
Strongarm 033065 SACL200 20 Metric Ton Low Height Single Acting Cylinder
Strongarm 033065 SACL200 20 Metric Ton Low Height Single Acting Cylinder:
Features:
- Product no. 033065
- Model no. SACL200
- Designed for use in confined areas
- Complies with ASME B-30.1
- Made of durable high strength alloy steel
- Complete with mounting holes for fixture attachment
- Heavy duty plunger return springs
- Grooved plunger end with threaded hole allows mounting of tilt saddles
- Finished in baked enamel for superior corrosion resistance
Specifications:
- Capacity @ 700 Bar (10,000 PSI): 20 Ton
- Collapsed Height: 2.01″
- Duty Level: Super Heavy Duty
- Effective Area: 4.39 in²
- Extended Height (B): 2.44″
- Oil Capacity: 1,9 in³
- Outside Diameter (D): 3.98″ x 3.00″
- Piston Rod Diameter (F): 2.01″
- Rated Capacity: 20 T
- Spring Return: Yes
- Stroke Length: 0.43″
- Top Dimension (L): 1.57″
- Top Dimension (M): 1.57″
- Top Dimension (U): 1.94″
- Top Dimension (V): 0.39″
