Machined Eye Bolts

Machined Eye Bolts

$2.22 – $141.98

Add to wishlist
UOM: N/A SKU: N/A Categories: ,
This image is for representative purposes only - the actual product may differ. Please refer to the Product Title and the Product Description for the most accurate information.

Description

Machined Eye Bolts

  • Made from forged carbon steel – quenched and tempered
  • Design factor proof load 2:1 WLL, ultimate load 5:1 WLL
Size
(inches)		 WLL
(lbs)		 Proof Load
(lbs)

1/4 x 1

 650 1,300

5/16 x 1-1/8

 1,200 2,400

3/8 x 1-1/4

 1,550 3,100

1/2 x 1-1/2

 2,600 5,200

5/8 x 1-3/4

 5,200 10,400

3/4 x 2

 7,200 14,400

7/8 x 2-1/4

 10,600 21,200

1 x 2-1/2

 13,300 26,600

1-1/4 x 3

 21,000 42,000

1-1/2 x 3-1/2

 24,000 48,000

Additional information

Weight N/A
Size

1/4" x 1", 5/16" x 1/1/8", 3/8" x 1-1/4", 1/2" x 1-1/2", 5/8" x 1-3/4", 3/4" x 2", 7/8" x 2-1/4", 1" x 2-1/2", 1-1/4" x 3", 1-1/2" x 3-1/2"
