Jet 390110 CC-10 10″ CC Series C-Clamp – Heavy Duty

$374.29

Backorder

UOM: EA SKU: 390110 Categories: , , UPC: 059629839393

Description

Jet 390110 CC-10 10″ CC Series C-Clamp – Heavy Duty

Jet 390110 CC-10 10″ CC Series C-Clamp – Heavy Duty:

Features:

  • Product no. 390110
  • Model no. CC-10
  • CC Series – Regular Throat Clamp – Heavy Duty
  • Made of industrial quality drop forged, heat-treated steel
  • Special retaining clips:
        • Secure the heavy duty swivel pads
        • Superior to crimped pads
  • Acme threaded screw provides:
        • Smooth operation
        • Even clamping pressure
  • Black oxide screw resists welding spatter

Specifications:

  • Clamping Pressure: 9,000 lb
  • Max. Opening: 9-1/2″
  • Throat Depth: 4-1/4″

Click here for more Jet C-Clamps

Comparison Chart for Regular Throat Clamps
Product no. Model no. Maximum Opening Throat Depth Clamping Pressure
390102 CC-2 2-3/16″ 1″ 3,330 lbs
390103 CC-3 2-5/8″ 1-1/2″ 4,350 lbs
390104 CC-4 4″ 1-3/4″ 5,300 lbs
390105 CC-5 4-5/8″ 2-1/16″ 5,900 lbs
390106 CC-6 6-1/4″ 2-1/2″ 7,650 lbs
390108 CC-8 7-1/2″ 3-1/4″ 8,850 lbs
390110 CC-10 9-1/2″ 4-1/4″ 9,000 lbs
390112 CC-12 11-9/16″ 4-1/2″ 13,000 lbs

Additional information

Weight 12.91 lbs
Brand Name

Clamp Type

C-Clamps
