Jet 140110 JHJ-22-1/2LP 22-1/2 Ton Hydraulic Bottle Jack – Low Profile

Description

Jet 140110 JHJ-22-1/2LP 22-1/2 Ton Hydraulic Bottle Jack – Low Profile

Jet 140110 JHJ-22-1/2LP 22-1/2 Ton Hydraulic Bottle Jack – Low Profile:

Features:

• Product no. 140110
• Model no. JHJ-22-1/2LP
• Low Profile model
• JET bottle jacks – a Canadian standard for over 45 years
• Work in upright, angle or horizontal positions
• Electrically welded base and cylinder ensure strength and eliminate leaks
• Special valving allows the handle to remain in the upright position when used horizontally
• Cleated steel lift saddle provides the safest operator conditions
• Convenient extension screw allows low pick up height adjustment
• Fully serviceable
• Common release valve assemblies and other interchangeable parts allow quick repairs
• Not affected by temperature extremes
• Adheres rigidly to the following standards:
  • • • JIS (Japanese Industrial Standards)
      • ANSI (American National Standards Institute)
• Tested to over 150% of rated capacities
• Made in Japan

Specifications:

• Closed Height: 7-1/8″
• Handle Type (# pieces): 1
• Head Screw Height: 1-9/16″
• Max. Height: 12-1/16″
• Piston Travel: 3-3/8″
• Product Weight: 19.404 lb (8.82 kg)
• Rated Capacity: 22-1/2 T
• Shipping Weight: 19.7 lb (9 kg)
• Size of Base: 7-3/16″ x 5-1/16″
