Fluke 5065521 323 True-RMS Clamp Meter
$291.19
Model no. 323
Only 2 Available (can be backordered)
Fluke 5065521 323 True-RMS Clamp Meter
The Fluke 5065521 323 True-RMS Clamp Meter includes:
- Test leads
- Soft case
- User’s manual
Features:
- Model no. 323
- Item no. 5065521
- A good basic troubleshooting tool for commercial and residential electricians
- Use to verify:
-
-
- Presence of load current, AC voltage
- Continuity of circuits, switches, fuses and contacts
-
-
- Rugged, reliable basic True-RMS clamp meter for measuring current up to 400 A
- Measures:
-
-
- AC current to 400 A
- AC voltage and DC voltage to 600 V
- Resistance to 4 kΩ with continuity detection
-
-
- Provides True RMS AC voltage and current for accurate measurements on non-linear signals
- Slim, ergonomic design for measuring in tight cable compartments
- Large, easy-to-read display
- Hold function captures a reading on the display
- CAT III 600 V, CAT IV 300 V safety rating
| Specifications | ||
| AC current | Range | 400.0 A |
| Accuracy | 2% ± 5 digits (45 Hz to 65 Hz) 2.5% ± 5 digits (65 Hz to 400 Hz) |
|
| DC current | Range | – |
| Accuracy | – | |
| AC voltage | Range | 600.0 V |
| Accuracy | 1.5% ± 5 digits | |
| DC voltage | Range | 600.0 V |
| Accuracy | 1.0% ± 5 digits | |
| Resistance | Range | 400.0 Ω/ 4000 Ω |
| Accuracy | 1.0% ± 5 digits | |
| Continuity | ≤ 70 Ω | |
| Capacitance | – | |
| Frequency | – | |
| AC response | True-RMS | |
| Backlight | – | |
| Data hold | Yes | |
| Contact temperature | – | |
| Min/Max | – | |
| Size | H x W x D (mm) | 207 x 75 x 34 |
| Max wire diameter | 30 mm (600 MCM) | |
| Weight | 265 g | |
| Category rating | CAT III 600 V CAT IV 300 V |
|
| Warranty | Two-year | |
| Weight | 5 lbs |
|---|---|
| Brand Name | |
| Instruments | Electrical Testers and Meters |
