PLS PLS180RZ Cross-Line Red Laser Level – Bare Tool

Description

PLS PLS180RZ Cross-Line Red Laser Level – Bare Tool

The PLS PLS180RZ Cross-Line Red Laser Level – Bare Tool includes:

• PLS 180R Laser Level
• BP5 Alkaline Battery Pack – 3 batteries
• Safety Sheet
• Quick Reference Guide
• Canvas Pouch

Features:

• Part number: 5017279
• SKU: PLS180RZ
• Description: Cross Line Laser – Bare Tool
• Self-leveling cross line laser
• Pendulum lock secures the laser during transport or if dropped

Typical Applications:

• Wall construction
• Acoustic ceiling installation
• Tile installation
• Residential construction
• Commercial construction

Specifications:

• Line Fan Angle: Horizontal ≥ 180º, Vertical ≥ 130º
• Laser working range: ≤ 15 m (50 ft.)
• Line laser width: ≤ 2 mm @ 5 m
• Accuracy: ≤ 3 mm @ 10 m (≤ 1/8 in at 30 ft.)
• Laser leveling system: Automatic, Pendulum
• Laser leveling range: 4º
• Operating temperature: -10 °C to 50 °C (14 °F to 122 °F)
• Batteries: 3 – Alkaline AA
• Laser Class: Class II
• Wavelength: 635 nm ± 5 nm
• Maximum Output Power: < 1 mW
• IP Rating: IP 54
• Operating Time: ≥ 8 hours continuous (both lasers)
• Dimensions: (HxWxL): 4.6″ x 2.5″ x 4.1″ (116 mm x 64 mm x 104 mm )
• Weight: 1.3 lbs (0.6 kg)

Available model variations:

• PLS3RZ 3-Point Red Laser Level
• PLS5RZ 5-Point Red Laser Level
• PLS6RZ 6-Point Red Laser Level
• PLS180RZ Cross-Line Red Laser Level
