Wire Rope Galvanized – 7 x 7

$40.00$80.00

Hot Dipped Galvanized
1/16"

$40.00

3/32"

$55.00

1/8"

$80.00

Wire Rope Galvanized – 7 x 7

Wire Rope Galvanized

$40.00$80.00

Clear
SKU: N/A Categories: ,

Product Description

Wire Rope Galvanized – 7 x 7

  • Preformed galvanized cables/wire rope
  • Recommended when flexibility, high strength and fatigue resistance are needed
  • 7 x 7 construction is generally used for small diameters
  • 7 x 7 construction is less flexible than 7 x 19, but has better abrasion resistance
  • NOTE: Wire Rope is sold by the full roll only
Diameter
(inches)
Weight
(lbs/1000 ft.)
Nominal
B/S (lbs)*
Number of  feet per roll
1/16 7.5 480 500
3/32 16.0 920 500
1/8 28.5 1,700 500
*B/S = Breaking Strength



Vanguard Steel Ltd. warns to never exceed 20% of the wire rope breaking strength.

Additional Information

Diameter

1/16″, 3/32″, 1/8″, 3/16″, 3/32″, 1/8″, 5/32″, 3/16″, 1/4″, 5/16″, 3/8″
