Malleable Split Ring Hangers Electrogalvanized

$1.47$6.43

Clear
SKU: N/A Category:

Description

Malleable Split Ring Hangers Electrogalvanized

  • Material: Cast iron
  • Finish:¬†Electrogalvanized
  • Recommended for suspending stationary non-insulated pipe lines
  • Allows for piping runs close to ceiling or walls
  • Conforms with Federal specification WW-H 171 (Type 25), Manufacturers Standardization Society (MSS) SP-58 (Type 12)

Malleable Split Ring Hanger

Part no./SKU Pipe Size Outer
Diameter
Rod Size A B Static Load
F
4550037EG 3/8″ 0.675″ 3/8″ 1-5/16″ 3/8″ 180 lbs
4550050EG 1/2″ 0.840″ 3/8″ 1-1/2″ 3/8″ 180 lbs
4550075EG 3/4″ 1.050″ 3/8″ 1-3/4″ 7/16″ 180 lbs
45500100EG 1″ 1.315″ 3/8″ 2″ 7/16″ 180 lbs
45500125EG 1-1/4″ 1.660″ 3/8″ 2-3/8″ 1/2″ 180 lbs
45500150EG 1-1/2″ 1.900″ 3/8″ 2-5/8″ 1/2″ 180 lbs
45500200EG 2″ 2.375″ 3/8″ 3-1/8″ 1/2″ 180 lbs
45500250EG 2-1/2″ 2.875″ 1/2″ 3-1/4″ 5/8″ 300 lbs
45500300EG 3″ 3.500″ 1/2″ 4-3/8″ 5/8″ 300 lbs
45500400EG 4″ 4.500″ 1/2″ 5-3/8″ 11/16″ 300 lbs

Additional information

Weight N/A
Pipe Size

3/8", 1/2", 3/4", 1", 1-1/4", 1-1/2", 2", 2-1/2", 3", 4"
