Jet 120257 10 Ton SBT Series Manual Trolley – Heavy Duty

Jet SBT Series Manual Trolley - Heavy Duty
Jet SBT Series Manual Trolley - Parts

$1,400.96

Special Order Item (Ships within 3-5 Business Days)

Available on backorder

SKU: 120257 Categories: ,

Product Description

Jet 120257 10 Ton SBT Series Manual Trolley – Heavy Duty

  • Product no. 120257
  • Designed to move loads by pulling on the hoist load chain in the direction of travel
  • Double-sealed ball bearings ensure long life
  • Specially hardened steel wheels comply with ANSI B30.11 specifications – certificate included
  • Integrated drop stops/bumpers take the load in case of wheel failure and prevent the wheels from contacting other trolleys on the track
  • Can be adjusted to fit a range of flanges and beams
  • Equipped for use on up to 8″ beam widths
  • Can be installed or removed at any point along the track
  • Can be used on straight or curved H, I, W and S-beams
SBT Series Manual Trolley Specifications and Comparison Chart
Product no. Rated Capacity (tons) Rated Capacity (lbs) I-Beam Flange Width  Minimum Radius Curve Weight lbs (kg)
120251 1/2 1,100 3-1/4″ to  8-1/32″ 36″ 20.7 (9.4)
120252 1 2,200 4″ to 8-1/32″ 40″ 34.2 (15.6)
120253 1-1/2 3,300 4″ to 8-1/32″ 40″ 43.3 (19.7)
120254 2 4,400 4″ to 8-1/32″ 43″ 56.5 (25.7)
120255 3 6,600 4″ to 8-1/32″ 51″ 90.5 (41.1)
120256 5 11,000 4-1/2″ to 8-1/32″ 55″ 124.9 (56.8)
120257 10 22,000 4-15/16″ to 8-1/32″ 67″ 233.6 (106.1)



Trolley Dimensions
Rated Capacity (tons) A B C D E F G
1/2 12-13/32″ 8-1/2″ 8-1/8″ 2-1/4″ 1-1/4″ 1/8″ 4-41/64″
1 13-1/8″ 10-1/4″ 9-3/8″ 2-15/16″ 1-1/4″ 1/8″ 5-13/64″
1-1/2 13-15/16″ 10-3/4″ 10″ 3-3/8″ 1-1/8″ 1/8″ 5-1/4″
2 13-29/32″ 11-7/8″ 10-15/16″ 3-1/2″ 1-1/8″ 1/8″ 6-1/16″
3 14-5/8″ 13-1/2″ 13-15/16″ 4-5/16″ 13/16″ 1/8″ 7-21/32″
5 15-15/32″ 15-3/8″ 15-29/32″ 4-3/4″ 13/16″ 1/8″ 8-3/4″
10 17-11/64″ 18-1/2″ 19-5/8″ 5-29/32″ 1-1/4″ 1/8″ 11″



Optional Extension Shaft Kits:

  • For converting trolleys for use on beams with flange widths from 8″ to 12″
  • Includes suspension shaft, washers, castle nuts and split pins
  • Fit SBT and SGT series trolleys
Optional Extension Shaft Kits for SBT & SGT trolleys
Product no. Model no. Works on
124202 JTES-0512 1/2 ton trolleys
124203 JTES-1012 1 ton trolleys
124204 JTES-1512 1.5 ton trolleys
124205 JTES-2012 2 ton trolleys
124206 JTES-3012 3 ton trolleys
124207 JTES-5012 5 ton trolleys
124208 JTES-10012 10 ton trolleys

Additional Information

Weight 229.84 lbs
Brand Name

Jet Equipment and Tools
